Perkins Diesel Generator ARK-P 1650 S5

ARK-P 1650 S5 Diesel Generator – Maximum Power, Superior Performance, and Perkins Reliability

The ARK-P 1650 S5 diesel generator, produced by Arken Power Solutions, delivers 1510 kVA prime and 1660 kVA standby power, providing exceptional efficiency and durability for industrial and commercial energy needs. Powered by the Perkins 4012-46TAG2A 12-cylinder, turbocharged, air-to-air cooled engine, it ensures long-lasting performance, low fuel consumption, and stable operation under continuous heavy load. Its STAMFORD S7L1D-C alternator with electronic AVR offers ±1% voltage regulation and <5% THD, guaranteeing clean, stable, and consistent power output. Built in accordance with ISO 8528 and ISO 3046 standards, the ARK-P 1650 S5 operates quietly at 91 dBA, features a corrosion-resistant canopy, and is backed by a 1-year or 1000-hour warranty, making it a robust and reliable solution for both continuous and standby power generation.

Power Prime (kVA / kW)

1510 / 1208

Power Standby (kVA / kW)

1660 / 1328

Speed (r.p.m)

1500

Standard Voltage

400/230VAC

Power Factor(Cos Phi)

0.8
BrandPerkins
Power PRP [kW]1267
Model4012-46TAG2A
N° of Cylinders / Valves12/ 48
Engine Type4
Displacement [lt]45.8
AspirationTurbocharge and Aftercooler System
Bore[mm] x Stroke[mm]160x190
Compression Ratio13:1
Air FilterHeavy Duty
Cooling MethodWater Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)210
Governor TypeElectronic
Electrical System24VDC
Battery Charger Current55A
Oil Capacity [lt]177
Exhaust Gas Flow PRP [m3/min]320
Exhaust Gas Temp. [°C]455
Air Flow PRP [m3/min]120
Cooling Air Flow PRP [m3/min]32.4
Starter Power (kW)8.2
Standard Battery Voltage [V]24VDC
Standard Battery Capacity4x150Ah
Standard Battery TypeMaintenance-Free Lead Acid
BrandStamford
ModelS7L1D-C
Voltage400 /230 VAC
Number of Phase3
Power Factor0.8
Number of Poles4
Connection TypeStar
BearingSingle

Datasheet
