Baudouin Diesel Generator ARK-B 150 S5

ARK-B 150 S5 Diesel Generator – Powerful and Durable Energy Solution

The ARK-B 150 S5 diesel generator from Arken Power Solutions provides 140 kVA prime and 150 kVA standby power with the Baudouin 6M11G150/5 6-cylinder, turbocharged, aftercooled engine. Designed for performance and longevity, it delivers exceptional efficiency and reliable operation under demanding conditions.

Its Stamford UCI274E alternator offers 93.5% efficiency, ±1% voltage regulation, and <5% THD, ensuring clean, stable energy output. Built according to ISO 8528 and ISO 3046, the ARK-B 150 S5 operates at 72.1 dBA and includes a 2-year or 1000-hour warranty, guaranteeing consistent, high-quality power delivery.

Power Prime (kVA / kW)

140 / 112

Power Standby (kVA / kW)

150 / 120

Speed (r.p.m)

1500

Standard Voltage

400/230VAC

Power Factor(Cos Phi)

0.8
BrandBAUDOUIN
Power PRP [kW]128
Model6M11G150/5
N° of Cylinders / Valves6/12
Engine Type4
Displacement [lt]6.75
AspirationTurbocharged - Aftercooled
Bore[mm] x Stroke[mm]105x130
Compression Ratio18:1
Air FilterHeavy Duty
Cooling MethodWater Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)17
Governor TypeElectronic
Electrical System12VDC
Battery Charger Current80
Oil Capacity [lt]17
Exhaust Gas Flow PRP [m3/min]21,8
Exhaust Gas Temp. [°C]≤550
Air Flow PRP [m3/min]8.28
Cooling Air Flow PRP [m3/min]304.5
Starter Power (kW)6
Standard Battery Voltage [V]12VDC
Standard Battery Capacity1x105Ah
Standard Battery TypeMaintenance-Free Lead Acid
BrandStamford
ModelUCI274E
Voltage400 /230 VAC
Number of Phase3
Power Factor0.8
Number of Poles4
Connection TypeStar
BearingSingle

Datasheet
