Baudouin Diesel Generator ARK-B 275 L5

ARK-B 275 L5 Diesel Generator – Maximum Efficiency, Reliable Energy

The ARK-B 275 L5, developed by Arken Power Solutions, offers 240 kVA prime and 270 kVA standby power with the Baudouin 6M16G275/5 engine and LINZ PRO28S C/4 alternator. Designed for industrial durability, it features electronic AVR, < 3.1% THD, and ± 1% voltage stability, ensuring consistent and clean power delivery. Its compact, corrosion-resistant canopy operates quietly at 74.3 dBA and meets ISO 8528 and ISO 3046 standards. Backed by a 2-year / 1000-hour warranty, the ARK-B 275 L5 offers long-lasting reliability and superior performance for continuous or standby energy generation.

Power Prime (kVA / kW)

240 / 192

Power Standby (kVA / kW)

270 / 216

Speed (r.p.m)

1500

Standard Voltage

400/230VAC

Power Factor(Cos Phi)

0.8
BrandBAUDOUIN
Power PRP [kW]240
Model6M16G275/5
N° of Cylinders / Valves6/12
Engine Type4 Stroke
Displacement [lt]9.726
AspirationTurbocharge and Aftercooler System
Bore[mm] x Stroke[mm]126x130
Compression Ratio17:1
Air FilterHeavy Duty
Cooling MethodWater Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)44
Governor TypeElectronic
Electrical System24VDC
Battery Charger Current55
Oil Capacity [lt]26
Exhaust Gas Flow PRP [m3/min]46,8
Exhaust Gas Temp. [°C]≤600
Air Flow PRP [m3/min]16.8
Cooling Air Flow PRP [m3/min]415
Starter Power (kW)8.5
Standard Battery Voltage [V]24VDC
Standard Battery Capacity2x75Ah
Standard Battery TypeMaintenance-Free Lead Acid
BrandLinz
ModelPRO28S C/4
Voltage400 /230 VAC
Number of Phase3
Power Factor0.8
Number of Poles4
Connection TypeStar
BearingSingle
