Baudouin Diesel Generator ARK-B 450 N5

ARK-B 450 N5 Diesel Generator – Efficient and Powerful Energy Solution

The ARK-B 450 N5 diesel generator by Arken Power Solutions provides 400 kVA prime and 450 kVA standby power using the Baudouin 6M21G440/5 6-cylinder, turbocharged, water-cooled engine. Designed for industrial-grade applications, it offers strong performance, excellent fuel economy, and consistent operation under variable loads.

Featuring a NEKRA ARK 4FG alternator with 95.1% efficiency, ±1% voltage regulation, and <5% THD, it ensures stable and high-quality power output. Compliant with ISO 8528 and ISO 3046 standards, the ARK-B 450 N5 operates at 85 dBA and includes a 2-year or 1000-hour warranty, delivering reliable power for continuous or standby use.

Power Prime (kVA / kW)

400 / 320

Power Standby (kVA / kW)

450 / 360

Speed (r.p.m)

1500

Standard Voltage

400/230VAC

Power Factor(Cos Phi)

0.8
BrandBAUDOUIN
Power PRP [kW]368
Model6M21G440/5
N° of Cylinders / Valves6/24
Engine Type4
Displacement [lt]12.54
AspirationTurbocharged - Aftercooled
Bore[mm] x Stroke[mm]127x165
Compression Ratio16:1
Air FilterHeavy Duty
Cooling MethodWater Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)55
Governor TypeElectronic
Electrical System24VDC
Battery Charger Current70
Oil Capacity [lt]30
Exhaust Gas Flow PRP [m3/min]63
Exhaust Gas Temp. [°C]≤580
Air Flow PRP [m3/min]25
Cooling Air Flow PRP [m3/min]398
Starter Power (kW)7.5
Standard Battery Voltage [V]24VDC
Standard Battery Capacity2x105Ah
Standard Battery TypeMaintenance-Free Lead Acid
BrandNEKRA
ModelARK 4FG
Voltage400 /230 VAC
Number of Phase3
Power Factor0.8
Number of Poles4
Connection TypeStar
BearingSingle
