Cummins Diesel Generator ARK-C 2250 N5

ARK-C 2250 N5 Diesel Generator – Maximum Industrial Power, Efficiency, and Reliable Cummins Performance

The ARK-C 2250 N5 diesel generator, manufactured by Arken Power Solutions, delivers 2040 kVA prime and 2247 kVA standby power, ensuring unmatched performance and reliability for large-scale industrial and commercial operations. Powered by the Cummins QSK60-G4 16-cylinder, turbocharged, aftercooled, water-cooled engine, it offers superior efficiency, long service life, and consistent operation under heavy loads. Its NEKRA ARK 7J alternator with electronic AVR guarantees ±1% voltage regulation and <5% THD, delivering clean, stable, and continuous power output. Built in compliance with ISO 8528 and ISO 3046 standards, the ARK-C 2250 N5 operates at 85 dBA, features a corrosion-resistant canopy, and includes a 1-year or 1000-hour warranty, making it a dependable and efficient solution for both continuous and standby power generation.

Power Prime (kVA / kW)

2040 / 1632

Power Standby (kVA / kW)

2247 / 1797,6

Speed (r.p.m)

1500

Standard Voltage

400/230VAC

Power Factor(Cos Phi)

0,8
BrandCummins
Power PRP [kW]1730
ModelQSK60-G4
N° of Cylinders / Valves16
Engine Type4 Stroke
Displacement [lt]60,2
AspirationTurbocharger and Aftercooler System
Bore[mm] x Stroke[mm]159x190
Compression Ratio14.5:1
Air Filter Heavy Duty
Cooling Method Water Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)456
Governor TypeECM (Engine Control Modul)
Electrical System24VDC
Battery Charger Current55
Oil Capacity [lt]280
Exhaust Gas Temp. [°C]5,190
Air Flow PRP [m3/min]430
Cooling Air Flow PRP [m3/min]2,264
Starter Power (kW)TBA
Standard Battery Voltage [V]24VDC
Standard Battery Capacity4x150Ah
Standard Battery Type Maintenance-Free Lead Acid
BrandNekra
ModelARK 7J
Voltage400 /230 VAC
Number of Phase3
Power Factor0,8
Number of Poles4
Connection TypeStar
BearingSingle

Datasheet
