Perkins Diesel Generator ARK-P 1250 N5

ARK-P 1250 N5 Diesel Generator – Maximum Power, Superior Efficiency, and Perkins Reliability

The ARK-P 1250 N5 diesel generator, developed by Arken Power Solutions, delivers 1125 kVA prime and 1230 kVA standby power, offering exceptional performance and durability for industrial and commercial energy needs. Powered by the Perkins 4008-30TAG3 8-cylinder, turbocharged, air-to-air cooled engine, it ensures superior fuel efficiency, long service life, and stable performance under demanding conditions. Its NEKRA ARK 6F alternator with electronic AVR provides ±1% voltage regulation and <5% THD, ensuring clean and consistent power output. Built in compliance with ISO 8528 and ISO 3046 standards, the ARK-P 1250 N5 operates quietly at 88 dBA, features a corrosion-resistant canopy, and includes a 2-year or 1000-hour warranty, making it a reliable and high-capacity solution for continuous and backup power generation.

Power Prime (kVA / kW)

1125 / 900

Power Standby (kVA / kW)

1230 / 984

Speed (r.p.m)

1500

Standard Voltage

400/230VAC

Power Factor(Cos Phi)

0.8
BrandPerkins
Power PRP [kW]947
Model4008-30TAG3
N° of Cylinders / Valves8/32
Engine Type4
Displacement [lt]30.5
AspirationTurbocharged - Air to air cooled
Bore[mm] x Stroke[mm]160x190
Compression Ratio13.6:1
Air FilterHeavy Duty
Cooling MethodWater Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)140
Governor TypeElectronic
Electrical System24VDC
Battery Charger Current55A
Oil Capacity [lt]153
Exhaust Gas Flow PRP [m3/min]203
Exhaust Gas Temp. [°C]473
Air Flow PRP [m3/min]84
Cooling Air Flow PRP [m3/min]1140
Starter Power (kW)8.2
Standard Battery Voltage [V]24VDC
Standard Battery Capacity4x105Ah
Standard Battery TypeMaintenance-Free Lead Acid
BrandNekra
ModelARK 6F
Voltage400 /230 VAC
Number of Phase3
Power Factor0.8
Number of Poles4
Connection TypeStar
BearingSingle
