Perkins Diesel Generator ARK-P 1650 N5

ARK-P 1650 N5 Diesel Generator – Maximum Industrial Power with Perkins Performance

The ARK-P 1650 N5 diesel generator, developed by Arken Power Solutions, delivers 1500 kVA prime and 1650 kVA standby power, providing reliable, high-performance energy for large-scale industrial and commercial operations. Powered by the Perkins 4012-46TAG2A 12-cylinder, turbocharged, air-to-air cooled engine, it ensures exceptional fuel efficiency, low emissions, and long-term durability under heavy load conditions. Its NEKRA ARK 7F alternator with electronic AVR offers ±1% voltage regulation and <5% THD, guaranteeing clean, stable, and consistent power output. Built in compliance with ISO 8528 and ISO 3046 standards, the ARK-P 1650 N5 operates at 91 dBA, features a corrosion-resistant canopy, and comes with a 2-year or 1000-hour warranty, making it a dependable and efficient energy solution for continuous and standby power generation.

Power Prime (kVA / kW)

1500 / 1200

Power Standby (kVA / kW)

1630 / 1304

Speed (r.p.m)

1500

Standard Voltage

400/230VAC

Power Factor(Cos Phi)

0.8
BrandPerkins
Power PRP [kW]1267
Model4012-46TAG2A
N° of Cylinders / Valves12/ 48
Engine Type4
Displacement [lt]45.8
AspirationTurbocharged - Air to air cooled
Bore[mm] x Stroke[mm]160x190
Compression Ratio13:1
Air FilterHeavy Duty
Cooling MethodWater Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)210
Governor TypeElectronic
Electrical System24VDC
Battery Charger Current55A
Oil Capacity [lt]177
Exhaust Gas Flow PRP [m3/min]320
Exhaust Gas Temp. [°C]455
Air Flow PRP [m3/min]120
Cooling Air Flow PRP [m3/min]32.4
Starter Power (kW)8.2
Standard Battery Voltage [V]24VDC
Standard Battery Capacity4x150Ah
Standard Battery TypeMaintenance-Free Lead Acid
BrandNekra
ModelARK 7F
Voltage400 /230 VAC
Number of Phase3
Power Factor0.8
Number of Poles4
Connection TypeStar
BearingSingle
