Sdec Diesel Generator ARK-S 1010 N5

ARK-S 1010 N5 Diesel Generator – Heavy-Duty, High-Efficiency, and Reliable SDEC Power

The ARK-S 1010 N5 diesel generator, engineered by Arken Power Solutions, delivers 920 kVA prime and 1010 kVA standby power, providing exceptional performance, reliability, and efficiency for industrial and commercial applications. Powered by the SDEC 6KTAA25-G320 6-cylinder, turbocharged, intercooled, water-cooled engine, it ensures excellent fuel economy, long service life, and stable operation under continuous heavy load. Its NEKRA ARK 6D alternator with electronic AVR guarantees ±1% voltage regulation and <5% THD, providing clean, stable, and consistent energy output. Built to comply with ISO 8528 and ISO 3046 standards, the ARK-S 1010 N5 operates efficiently at 72.7 dBA, features a corrosion-resistant canopy, and includes a 2-year or 1000-hour warranty, making it a dependable and high-performance power generation solution for both continuous and standby applications.

Power Prime (kVA / kW)

920 / 736

Power Standby (kVA / kW)

1010/ 808

Speed (r.p.m)

1500

Standard Voltage

400/230VAC

Power Factor(Cos Phi)

0,8
BrandSdec
Power PRP [kW]820
Model6KTAA25-G320
N° of Cylinders / Valves6/12
Engine Type4 Stroke
Displacement [lt]25,2
AspirationTurbocharger
Bore[mm] x Stroke[mm]170x185
Compression Ratio14.5:1
Air FilterReplaceable Element
Cooling MethodWater Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)N/A
Governor TypeECM
Electrical System24VDC
Battery Charger Current55A
Oil Capacity [lt]75
Exhaust Gas Flow PRP [m3/min]177,8
Exhaust Gas Temp. [°C]600
Air Flow PRP [m3/min]N/A
Cooling Air Flow PRP [m3/min]N/A
Starter Power (kW)9kW
Standard Battery Voltage [V]24VDC
Standard Battery Capacity4x105Ah
Standard Battery TypeMaintenance-Free Lead Acid
BrandNekra
ModelARK 6D
Voltage400 /230 VA
Number of Phase3
Power Factor0,8
Number of Poles4
Connection TypeStar
BearingSingle
