Sdec Diesel Generator ARK-S 115 N5

ARK-S 115 N5 Diesel Generator – Reliable, Efficient, and Industrial-Grade Power Solution

The ARK-S 115 N5 diesel generator, manufactured by Arken Power Solutions, delivers 100 kVA prime and 110 kVA standby power, providing reliable and efficient energy for industrial and commercial operations. Powered by the SDEC SC4H160D2 4-cylinder, turbocharged, intercooled, water-cooled engine, it ensures exceptional performance, fuel efficiency, and long service life under continuous load. Its NEKRA ARK 274C alternator with electronic AVR guarantees ±1% voltage regulation and <5% THD, ensuring stable and clean energy output. Built in compliance with ISO 8528 and ISO 3046 standards, the ARK-S 115 N5 operates quietly at 72 dBA, features a corrosion-resistant canopy, and includes a 2-year or 1000-hour warranty, making it a dependable and durable solution for both continuous and standby power generation.

Power Prime (kVA / kW)

100 / 80

Power Standby (kVA / kW)

110 / 88

Speed (r.p.m)

1500

Standard Voltage

400/230VAC

Power Factor(Cos Phi)

0,8
BrandSdec
Power PRP [kW]105
ModelSC4H160D2
N° of Cylinders / Valves4/16
Engine Type4 Stroke
Displacement [lt]4,3
AspirationTurbocharger
Bore[mm] x Stroke[mm]105X124
Compression Ratio16:1
Air FilterReplaceable Element
Cooling MethodWater Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)19,3
Governor TypeElectronic
Electrical System24VDC
Battery Charger Current55A
Oil Capacity [lt]13
Exhaust Gas Flow PRP [m3/min]16,3
Exhaust Gas Temp. [°C]600
Air Flow PRP [m3/min]7,39
Cooling Air Flow PRP [m3/min]185,4
Starter Power (kW)4,5kW
Standard Battery Voltage [V]24VDC
Standard Battery Capacity2x60Ah
Standard Battery TypeMaintenance-Free Lead Acid
BrandNekra
ModelARK 274C
Voltage400 /230 VAC
Number of Phase3
Power Factor0,8
Number of Poles4
Connection TypeStar
BearingSingle

Datasheet
