Дизельный генератор ARK-C 1130 S5 обеспечивает 1028 кВА номинальной и 1124 кВА резервной мощности, предлагая стабильную и эффективную работу для крупных промышленных и коммерческих объектов. Двигатель Cummins KTA38 и альтернатор STAMFORD обеспечивают непрерывную подачу энергии.
| Brand | Cummins |
| Power PRP [kW] | 880 |
| Model | KTA38-G14 |
| N° of Cylinders / Valves | 12 |
| Engine Type | 4 Stroke |
| Displacement [lt] | 37,8 |
| Aspiration | Turbocharger and Aftercooler System |
| Bore[mm] x Stroke[mm] | 159x159 |
| Compression Ratio | 13.9:1 |
| Air Filter | Heavy Duty |
| Cooling Method | Water Cooled (water + %50 antifreeze) |
| Total Coolant Capacity (lt) | 210 |
| Governor Type | Electronic |
| Electrical System | 24VDC |
| Battery Charger Current | 35 |
| Oil Capacity [lt] | 135 |
| Exhaust Gas Temp. [°C] | 3,051 |
| Air Flow PRP [m3/min] | ≤499 |
| Cooling Air Flow PRP [m3/min] | 1,14 |
| Starter Power (kW) | TBA |
| Standard Battery Voltage [V] | 24VDC |
| Standard Battery Capacity | 4x105Ah |
| Standard Battery Type | Maintenance-Free Lead Acid |
| Brand | Stamford |
| Model | S6L1D-E |
| Voltage | 400 /230 VAC |
| Number of Phase | 3 |
| Power Factor | 0,8 |
| Number of Poles | 4 |
| Connection Type | Star |
| Bearing | Single |
