Дизельный генератор Baudouin ARK-B 1275 L5

ARK-B 1275 L5 Diesel Generator – High Power, Superior Efficiency, Industrial Strength

The ARK-B 1275 L5 diesel generator, developed by Arken Power Solutions, delivers 1150 kVA prime and 1275 kVA standby power, ensuring exceptional performance for large-scale industrial and commercial operations. Powered by the Baudouin 12M33G1250/5 12-cylinder, turbocharged, aftercooled, water-cooled engine, it offers high efficiency, low fuel consumption, and reliable continuous power output. The LINZ PRO40M C/4 alternator with electronic AVR provides ±1% voltage regulation and <4% THD, guaranteeing clean, stable, and consistent power delivery. Designed in compliance with ISO 8528 and ISO 3046 standards, the ARK-B 1275 L5 operates at 91 dBA, features a corrosion-resistant canopy, and comes with a 2-year or 1000-hour warranty, making it a dependable and powerful energy solution for heavy-duty applications.

Номинальная мощность

1150 / 920

Максимальная мощность

1275 / 1020

Скорость

1500

Напряжение

400/230VAC

Коэффициент мощности

0.8
BrandBAUDOUIN
Power PRP [kW]1007
Model12M33G1250/5
N° of Cylinders / Valves12/48
Engine Type4 Stroke
Displacement [lt]39.2
AspirationTurbocharge and Aftercooler System
Bore[mm] x Stroke[mm]150x185
Compression Ratio15:1
Air FilterHeavy Duty
Cooling MethodWater Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)240
Governor TypeElectronic
Electrical System24VDC
Battery Charger Current55
Oil Capacity [lt]155
Exhaust Gas Flow PRP [m3/min]190
Exhaust Gas Temp. [°C]≤550
Air Flow PRP [m3/min]68.7
Cooling Air Flow PRP [m3/min]1525
Starter Power (kW)10
Standard Battery Voltage [V]24VDC
Standard Battery Capacity4x105Ah
Standard Battery TypeMaintenance-Free Lead Acid
BrandLinz
ModelPRO40M C/4
Voltage400 /230 VAC
Number of Phase3
Power Factor0.8
Number of Poles4
Connection TypeStar
BearingSingle

Datasheet
