Дизельный генератор ARK-C 580 S5 обеспечивает 530 кВА номинальной и 580 кВА резервной мощности, предлагая высокую эффективность и долговечность для промышленных и коммерческих задач. Двигатель Cummins M15 и альтернатор STAMFORD с AVR гарантируют чистую и стабильную энергию.
| Brand | Cummins |
| Power PRP [kW] | 458 |
| Model | M15-G8 |
| N° of Cylinders / Valves | 6 |
| Engine Type | 4 Stroke |
| Displacement [lt] | 14,5 |
| Aspiration | Turbocharger and Aftercooler System |
| Bore[mm] x Stroke[mm] | 130x163 |
| Compression Ratio | 23,1 |
| Air Filter | Heavy Duty |
| Cooling Method | Water Cooled (water + %50 antifreeze) |
| Total Coolant Capacity (lt) | 83,1 |
| Governor Type | Electronic PGI (CAN J1939) |
| Electrical System | 24VDC |
| Battery Charger Current | 90 |
| Oil Capacity [lt] | 52 |
| Exhaust Gas Flow PRP [m3/min] | 1158 |
| Exhaust Gas Temp. [°C] | ≤416 |
| Air Flow PRP [m3/min] | 535 |
| Cooling Air Flow PRP [m3/min] | 7,7 |
| Starter Power (kW) | TBA |
| Standard Battery Voltage [V] | 24VDC |
| Standard Battery Capacity | 2x105Ah |
| Standard Battery Type | Maintenance-Free Lead Acid |
| Brand | Stamford |
| Model | S5L1D-D |
| Voltage | 400 /230 VAC |
| Number of Phase | 3 |
| Power Factor | 0,8 |
| Number of Poles | 4 |
| Connection Type | Star |
| Bearing | Single |
