Генератор ARK-P 1000 S5 оснащён двигателем Perkins 4008-TAG1A и обеспечивает 920 кВА (prime) и 1010 кВА (standby).
Альтернатор STAMFORD с ±1% регулировкой напряжения и THD <5% гарантирует стабильную и чистую подачу энергии.
Соответствие ISO 8528 / ISO 3046 и гарантия 1 год / 1000 часов делают эту модель надёжным решением для крупных промышленных и коммерческих объектов.
| Brand | Perkins |
| Power PRP [kW] | 767 |
| Model | 4008-TAG1A |
| N° of Cylinders / Valves | 8/32 |
| Engine Type | 4 |
| Displacement [lt] | 30.56 |
| Aspiration | Turbocharged - Air to air cooled |
| Bore[mm] x Stroke[mm] | 160x190 |
| Compression Ratio | 13.6:1 |
| Air Filter | Heavy Duty |
| Cooling Method | Water Cooled (water + %50 antifreeze) |
| Total Coolant Capacity (lt) | 149 |
| Governor Type | Electronic |
| Electrical System | 24VDC |
| Battery Charger Current | 55A |
| Oil Capacity [lt] | 153 |
| Exhaust Gas Flow PRP [m3/min] | 183 |
| Exhaust Gas Temp. [°C] | 425 |
| Air Flow PRP [m3/min] | 69.4 |
| Cooling Air Flow PRP [m3/min] | 20.8 |
| Starter Power (kW) | 8.2 |
| Standard Battery Voltage [V] | 24VDC |
| Standard Battery Capacity | 4x105Ah |
| Standard Battery Type | Maintenance-Free Lead Acid |
| Brand | Stamford |
| Model | S6L1D-D |
| Voltage | 400 /230 VAC |
| Number of Phase | 3 |
| Power Factor | 0.8 |
| Number of Poles | 4 |
| Connection Type | Star |
| Bearing | Single |
