Дизельный генератор ARK-P 110 N5 с двигателем Perkins 1104C-44TAG2 обеспечивает 100 кВА (prime) и 110 кВА (standby), предлагая стабильное и экономичное энергоснабжение для промышленных и коммерческих объектов.
Альтернатор NEKRA ARK 274C с электронным AVR, точностью ±1% и THD <5% гарантирует чистое и стабильное напряжение.
Соответствует стандартам ISO 8528 / ISO 3046, уровень шума 72 дБА, гарантия 2 года / 1000 часов.
| Brand | Perkins |
| Power PRP [kW] | 90.1 |
| Model | 1104C-44TAG2 |
| N° of Cylinders / Valves | 4/8 |
| Engine Type | 4 |
| Displacement [lt] | 4.41 |
| Aspiration | Turbocharged - Air to air cooled |
| Bore[mm] x Stroke[mm] | 105x127 |
| Compression Ratio | 18.2:1 |
| Air Filter | Heavy Duty |
| Cooling Method | Water Cooled (water + %50 antifreeze) |
| Total Coolant Capacity (lt) | 12.6 |
| Governor Type | Electronic |
| Electrical System | 12VDC |
| Battery Charger Current | 65A |
| Oil Capacity [lt] | 8 |
| Exhaust Gas Flow PRP [m3/min] | 15,2 |
| Exhaust Gas Temp. [°C] | 514 |
| Air Flow PRP [m3/min] | 6.01 |
| Cooling Air Flow PRP [m3/min] | 165.6 |
| Starter Power (kW) | 3 kW |
| Standard Battery Voltage [V] | 12VDC |
| Standard Battery Capacity | 1x75Ah |
| Standard Battery Type | Maintenance-Free Lead Acid |
| Brand | Nekra |
| Model | ARK 274C |
| Voltage | 400 /230 VAC |
| Number of Phase | 3 |
| Power Factor | 0.8 |
| Number of Poles | 4 |
| Connection Type | Star |
| Bearing | Single |
