Cummins Diesel Generator ARK-C 1450 N5

ARK-C 1450 N5 Diesel Generator – High-Capacity, Industrial-Grade, and Reliable Cummins Power

The ARK-C 1450 N5 diesel generator, developed by Arken Power Solutions, delivers 1290 kVA prime and 1430 kVA standby power, providing superior reliability, performance, and fuel efficiency for heavy-duty industrial applications. Powered by the Cummins KTA50-G3 16-cylinder, turbocharged, aftercooled, water-cooled engine, it ensures long-lasting durability, smooth operation, and consistent output under continuous load. Its NEKRA ARK 7E alternator with electronic AVR guarantees ±1% voltage regulation and <5% THD, offering clean, stable, and efficient power generation. Built in compliance with ISO 8528 and ISO 3046 standards, the ARK-C 1450 N5 operates at 85 dBA, features a corrosion-resistant canopy, and comes with a 1-year or 1000-hour warranty, making it a dependable and high-performance solution for both continuous and standby energy requirements.

Power Prime (kVA / kW)

1290 / 1032

Power Standby (kVA / kW)

1430 / 1144

Speed (r.p.m)

1500

Standard Voltage

400/230VAC

Power Factor(Cos Phi)

0,8
BrandCummins
Power PRP [kW]1097
ModelKTA50-G3
N° of Cylinders / Valves16
Engine Type4 Stroke
Displacement [lt]50,3
AspirationTurbocharger and Aftercooler System
Bore[mm] x Stroke[mm]159x159
Compression Ratio13.9:1
Air Filter Heavy Duty
Cooling Method Water Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)415
Governor TypeElectronic
Electrical System24VDC
Battery Charger Current35
Oil Capacity [lt]177
Exhaust Gas Temp. [°C]3728
Air Flow PRP [m3/min]≤520
Cooling Air Flow PRP [m3/min]1605
Starter Power (kW)TBA
Standard Battery Voltage [V]24VDC
Standard Battery Capacity4x150Ah
Standard Battery Type Maintenance-Free Lead Acid
BrandNekra
ModelARK 7E
Voltage400 /230 VAC
Number of Phase3
Power Factor0,8
Number of Poles4
Connection TypeStar
BearingSingle

Datasheet
