Perkins Diesel Generator ARK-P 50 N5

ARK-P 50 N5 Diesel Generator – Compact, Efficient, and Reliable Power Solution

The ARK-P 50 N5 diesel generator, manufactured by Arken Power Solutions, delivers 45 kVA prime and 48 kVA standby power, offering high efficiency and reliability for commercial and industrial applications. Powered by the Perkins 1103A-33TG1 3-cylinder, turbocharged, water-cooled engine, it ensures exceptional fuel economy, durability, and consistent performance under varying loads. The NEKRA ARK 224DS alternator with electronic AVR provides ±1% voltage regulation and <5% THD, guaranteeing clean and stable power output. Built in accordance with ISO 8528 and ISO 3046 standards, the ARK-P 50 N5 operates quietly at 69.8 dBA, features a corrosion-resistant canopy, and comes with a 2-year or 1000-hour warranty, making it a dependable energy solution for continuous and backup power generation.

Power Prime (kVA / kW)

45 / 36

Power Standby (kVA / kW)

48 / 38,4

Speed (r.p.m)

1500

Standard Voltage

400/230VAC

Power Factor(Cos Phi)

0.8
BrandPerkins
Power PRP [kW]41.3
Model1103A-33TG1
N° of Cylinders / Valves3/6
Engine Type4
Displacement [lt]3.3
AspirationTurbocharged
Bore[mm] x Stroke[mm]105x127
Compression Ratio17.25:1
Air FilterHeavy Duty
Cooling MethodWater Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)10.2
Governor TypeMechanical
Electrical System12VDC
Battery Charger Current65A
Oil Capacity [lt]7.9
Exhaust Gas Flow PRP [m3/min]7,0
Exhaust Gas Temp. [°C]492
Air Flow PRP [m3/min]2.9
Cooling Air Flow PRP [m3/min]53
Starter Power (kW)3 kW
Standard Battery Voltage [V]12VDC
Standard Battery Capacity1x60Ah
Standard Battery TypeMaintenance-Free Lead Acid
BrandNekra
ModelARK 224DS
Voltage400 /230 VAC
Number of Phase3
Power Factor0.8
Number of Poles4
Connection TypeStar
BearingSingle

Datasheet
